VALENCIA PLUS Series 10-160KVA
VALENCIA PLUS Series
Online UPS Low frequency 10KVA to 120KVA (Three Phase in and Three phase out)
VALENCIA PLUS Series Energy efficiency with superior electrical protection
Low Frequency 3/3 UPS series 10-120KVA is an online
Transformer-based UPS with three phases in both input and output and an
output power factor of 0.9. This UPS Features an isolation transformer on the output side to provide galvanic isolation for the load connected to a 6-pulse rectifier and an optional 12-pulse rectifier model which can reduce the harmonic currents and increase the power factor considerably by reducing the amount of reactive power consumed.
VALENCIA PLUS series has been conceived to offer the best guarantees in meeting customers’ requirements and needs and has been designed with full respect for the most demanding environmental regulations.
VALENCIA PLUS series features power range from 10 to 120 KVA in a very compact format for easier installation. Plus, the reliability of the system can be increased with the installation of several redundant units or it can grow in parallel based on the needs of the installation.
On-line, double conversion, DSP control.
∙ Double input connection to increase the availability.
∙ Input power factor >0.99.
∙ Total harmonic distortion of input current (THDi) < 3%.
∙ Efficiency between 95% and 96%.
∙ Galvanic isolation transformer on the output inverter.
∙ Parallel for redundancy or increase the power capacity.
∙ Compatible with generating sets.
∙ Inverter manual operation/Smart Eco-mode.
∙ Prepared to bear computer loads with FP <0.9.
∙ Batt-Watch battery monitoring and care.
∙ Calculates available backup time in a long-term failure.
∙ Compact format to save on installation space.
∙ Easy installation, operation and maintenance.
∙ A wide range of control and monitoring options.
∙ Large variety of options available.
∙ SLC Greenergy solution.
Technical support and service
• Pre and post-sales advice.
• Start-up.
• Telephone technical support.
• Preventative/corrective intervention.
• Maintenance contracts.
• Remote maintenance contracts.
• Training courses.
Guaranteed energy for all environments
Data centers: ensure the functionality of environments and prevent losses caused by net failures.
IT-Networks: Prevent costs due to service interruptions or loss of information.
Financial services: Maintains online operability of financial transactions and operations.
Industrial processes: protect productivity in electrically complicated environments.
Telecommunications: Prevents supply failures that can suspend communication between subscribers.
Infrastructure: Safeguards the instruments/equipment and ensures the proper management of the systems.
